Camera | ||||
Image Sensor | 1/2.8" CMOS | |||
Pixel | 2 MP | |||
Max. Resolution | 1920 (H) × 1080 (V) | |||
ROM | 128 MB | |||
RAM | 256 MB | |||
Electronic Shutter Speed | 1/3 s–1/30,000 s | |||
Scanning System | Progressive | |||
Min. Illumination | 0.005lux@F1.6 (Color, 30 IRE); 0.0005lux@F1.6 (B/W, 30 IRE) | |||
Lens | ||||
Focal Length | 2.7 mm–11 mm | |||
Max. Aperture | F1.6–F3.0 | |||
Field of View | H: 99.1°–31.9° V: 53.4°–18.0° D: 117.7°–36.6° | |||
Optical Zoom | 4× | |||
Focus Control | Auto; semi-auto; manual | |||
Close Focus Distance | 1 m (3.28 ft) | |||
DORI Distance | Detect | Observe | Recognize | Identify |
151.7 m (497.70 ft) | 59.9 m (196.52 ft) | 30.3 m (99.41 ft) | 15.2 m (49.87 ft) | |
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | ||||
PTZ | ||||
Pan/Tilt Range | Pan: 0° to 355°; Tilt: 0° to +90° (When the vertical field of view is between 0° and 10°, the device case will block part of the image) | |||
Manual Control Speed | Pan: 0.1°–100°/s Tilt: 0.1°–60°/s | |||
Preset Speed | Pan: 100°/s; Tilt: 60°/s | |||
Preset | 300 | |||
Tour | 8 (up to 32 presets per tour) | |||
Power-off Memory | Yes | |||
Idle Motion | Preset; Tour | |||
PTZ Protocol | DH-SD Pelco-P/D (Auto recognition) | |||
Video | ||||
Resolution | 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480) | |||
Video Frame Rate | 1080p (25/30 fps); 720p (25/30/50/60 fps) | |||
Day/Night | Yes | |||
BLC | Yes | |||
WDR | DWDR | |||
HLC | Yes | |||
White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp | |||
Gain Control | Auto/Manual | |||
Noise Reduction | 2D NR; 3D NR | |||
Defog | Electronic | |||
Digital Zoom | 16× | |||
Image Rotation | 180° | |||
S/N Ratio | ≥50 dB | |||
Function | ||||
CVI Product Output Mode | TVI;CVI;CVBS;AHD (CVBS is only used for debugging) | |||
Certification | ||||
Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpart B, ANSI C63.4-2014 UL: UL60950-1+CAN/CSA C22.2, No.60950-1 | |||
Port | ||||
Analog Output | 1 channel (CVBS/CVI output, BNC) | |||
RS-485 | 1 (baud rate range: 1200 bps–9600 bps) | |||
Power | ||||
Power Supply | 12VDC,1.5 A ± 10% | |||
Power Consumption | Basic: 7 W Max.: 9 W (PTZ) | |||
Environment | ||||
Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) | |||
Operating Humidity | ≤95% (RH) | |||
Protection | IP66; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection | |||
Structure | ||||
Product Dimensions | 88.9 mm × Φ122.0 mm (3.50" × Φ4.80") | |||
Net Weight | 0.6 kg (1.32 lb) | |||
Gross Weight | 0.65 kg (1.43 lb) |
